I’m building a web application for acoustic measurements. I would like the user to be able to play a sinusoidal sweep and record it simultaneously. The playback and the recording must be in sync.
I’m using streamlit, streamlit-webrtc and pydub, as sounddevice is sadly unusable in an online settings as far as I understand.
Unfortunately I’m still a beginner and I’m having trouble understanding this code that I found in the streamlit-webrtc examples, especially the app_sendonly_audio function:
# import asyncio
import logging
import queue
import threading
# import urllib.request
from pathlib import Path
from typing import List, NamedTuple, Optional
# import av
# import cv2
import matplotlib.pyplot as plt
import numpy as np
import pydub
import streamlit as st
# from aiortc.contrib.media import MediaPlayer
from numba import jit
from scipy import signal
from scipy.io import wavfile
# from maad import sound
# from maad import util
from streamlit_webrtc import (
RTCConfiguration,
WebRtcMode,
# WebRtcStreamerContext,
webrtc_streamer,
)
HERE = Path(__file__).parent
logger = logging.getLogger(__name__)
RTC_CONFIGURATION = RTCConfiguration(
{"iceServers": [{"urls": ["stun:stun.l.google.com:19302"]}]}
)
def main():
st.header("WebRTC demo")
pages = {
"WebRTC is sendonly and audio frames are visualized with matplotlib (sendonly)": app_sendonly_audio,
# noqa: E501
"Plot audio representation with scikit-maad": app_room_measurements,
}
page_titles = pages.keys()
page_title = st.sidebar.selectbox(
"Choose the app mode",
page_titles,
)
st.subheader(page_title)
page_func = pages[page_title]
page_func()
logger.debug("=== Alive threads ===")
for thread in threading.enumerate():
if thread.is_alive():
logger.debug(f" {thread.name} ({thread.ident})")
def app_sendonly_audio():
"""A sample to use WebRTC in sendonly mode to transfer audio frames
from the browser to the server and visualize them with matplotlib
and `st.pyplot`."""
webrtc_ctx = webrtc_streamer(
key="sendonly-audio",
mode=WebRtcMode.SENDONLY,
audio_receiver_size=256,
rtc_configuration=RTC_CONFIGURATION,
media_stream_constraints={"audio": True},
)
fig_place = st.empty()
fig, [ax_time, ax_freq] = plt.subplots(
2, 1, gridspec_kw={"top": 1.5, "bottom": 0.2}
)
sound_window_len = 5000 # 5s
sound_window_buffer = None
while True:
if webrtc_ctx.audio_receiver:
try:
audio_frames = webrtc_ctx.audio_receiver.get_frames(timeout=1)
except queue.Empty:
logger.warning("Queue is empty. Abort.")
break
sound_chunk = pydub.AudioSegment.empty()
for audio_frame in audio_frames:
sound = pydub.AudioSegment(
data=audio_frame.to_ndarray().tobytes(),
sample_width=audio_frame.format.bytes,
frame_rate=audio_frame.sample_rate,
channels=len(audio_frame.layout.channels),
)
sound_chunk += sound
if len(sound_chunk) > 0:
if sound_window_buffer is None:
sound_window_buffer = pydub.AudioSegment.silent(
duration=sound_window_len
)
sound_window_buffer += sound_chunk
if len(sound_window_buffer) > sound_window_len:
sound_window_buffer = sound_window_buffer[-sound_window_len:]
if sound_window_buffer:
# Ref: https://own-search-and-study.xyz/2017/10/27/python%E3%82%92%E4%BD%BF%E3%81%A3%E3%81%A6%E9%9F%B3%E5%A3%B0%E3%83%87%E3%83%BC%E3%82%BF%E3%81%8B%E3%82%89%E3%82%B9%E3%83%9A%E3%82%AF%E3%83%88%E3%83%AD%E3%82%B0%E3%83%A9%E3%83%A0%E3%82%92%E4%BD%9C/ # noqa
sound_window_buffer = sound_window_buffer.set_channels(
1
) # Stereo to mono
sample = np.array(sound_window_buffer.get_array_of_samples())
ax_time.cla()
times = (np.arange(-len(sample), 0)) / sound_window_buffer.frame_rate
ax_time.plot(times, sample)
ax_time.set_xlabel("Time")
ax_time.set_ylabel("Magnitude")
spec = np.fft.fft(sample)
freq = np.fft.fftfreq(sample.shape[0], 1.0 / sound_chunk.frame_rate)
freq = freq[: int(freq.shape[0] / 2)]
spec = spec[: int(spec.shape[0] / 2)]
spec[0] = spec[0] / 2
ax_freq.cla()
ax_freq.plot(freq, np.abs(spec))
ax_freq.set_xlabel("Frequency")
ax_freq.set_yscale("log")
ax_freq.set_ylabel("Magnitude")
fig_place.pyplot(fig)
else:
logger.warning("AudioReciver is not set. Abort.")
break
This function records audio from the user selected input device and plots its waveform with matplotlib. I would like to be able to play a sinusoidal sweep and simultaneously record it.
This is my code for the generation of the sweep:
def app_room_measurements():
audio_files_path = r"data/audio_files"
sweep_string = ""
inv_filter_string = ""
ir_string = ""
@jit(nopython=True)
def fade(data, gain_start, gain_end):
"""
Create a fade on an input object
Parameters
----------
:param data: The input array
:param gain_start: The fade starting point
:param gain_end: The fade ending point
Returns
-------
data : object
An input array with the fade applied
"""
gain = gain_start
delta = (gain_end - gain_start) / (len(data) - 1)
for i in range(len(data)):
data[i] = data[i] * gain
gain = gain + delta
return data
@jit(nopython=True)
def generate_exponential_sweep(
sweep_duration, sr, starting_frequency, ending_frequency
):
"""
Generate an exponential sweep using Farina's log sweep theory
Parameters
----------
:param sweep_duration: The duration of the excitement signal (in seconds)
:param sr: The sampling frequency
:param starting_frequency: The starting frequency of the excitement signal
:param ending_frequency: The ending frequency of the excitement signal
Returns
-------
exponential_sweep : array
An array with the fade() function applied
"""
time_in_samples = sweep_duration * sr
exponential_sweep = np.zeros(time_in_samples, dtype=np.double)
for n in range(time_in_samples):
t = n / sr
exponential_sweep[n] = np.sin(
(2.0 * np.pi * starting_frequency * sweep_duration)
/ np.log(ending_frequency / starting_frequency)
* (
np.exp(
(t / sweep_duration)
* np.log(ending_frequency / starting_frequency)
)
- 1.0
)
)
number_of_samples = 50
exponential_sweep[-number_of_samples:] = fade(
exponential_sweep[-number_of_samples:], 1, 0
)
return exponential_sweep
@jit(nopython=True)
def generate_inverse_filter(
sweep_duration, sr, exponential_sweep, starting_frequency, ending_frequency
):
"""
Generate an inverse filter using Farina's log sweep theory
Parameters
----------
:param sweep_duration: The duration of the excitement signal (in seconds)
:param sr: The sampling frequency
:param exponential_sweep: The resulting array of the generate_exponential_sweep() function
:param starting_frequency: The starting frequency of the excitement signal
:param ending_frequency: The ending frequency of the excitement signal
Returns
-------
inverse_filter : array
The array resulting from applying an amplitude envelope to the exponential_sweep array
"""
time_in_samples = sweep_duration * sr
amplitude_envelope = np.zeros(time_in_samples, dtype=np.double)
inverse_filter = np.zeros(time_in_samples, dtype=np.double)
for n in range(time_in_samples):
amplitude_envelope[n] = pow(
10,
(
(-6 * np.log2(ending_frequency / starting_frequency))
* (n / time_in_samples)
)
* 0.05,
)
inverse_filter[n] = exponential_sweep[-n] * amplitude_envelope[n]
return inverse_filter
def deconvolve(ir_sweep, ir_inverse):
"""
A deconvolution of the exponential sweep and the relative inverse filter
Parameters
----------
:param ir_sweep: The resulting array of the generate_exponential_sweep() function
:param ir_inverse: The resulting array of the generate_inverse_filter() function
Returns
-------
normalized_ir : array
An N-dimensional array containing a subset of the discrete linear deconvolution of ir_sweep with ir_inverse
"""
impulse_response = signal.fftconvolve(
ir_sweep, ir_inverse, mode="full"
) # Convolve two N-dimensional arrays using FFT
normalized_ir = impulse_response * (1.0 / np.max(abs(impulse_response)))
return normalized_ir
sample_rate_option = st.selectbox("Select the desired sample rate", (44100, 48000))
sweep_duration_option = st.selectbox("Select the duration of the sweep", (3, 7, 14))
max_reverb_option = st.selectbox(
"Select the expected maximum reverb decay time", (1, 2, 3, 5, 10)
)
st.caption(
"""
Note that longer sweeps provide more accuracy,
but even short sweeps can be used to measure long decays
"""
)
def write_wav_file(file_name, rate, data):
save_file_path = os.path.join(audio_files_path, file_name)
wavfile.write(save_file_path, rate, data)
st.success(f"File successfully written to audio_files_path as:>> {file_name}")
def play_sweep(wavefile_name):
read_file_path = os.path.join(audio_files_path, wavefile_name)
# Extract data and sampling rate from file
sample_rate, data = wavfile.read(read_file_path)
stop_button = st.button("Stop")
if "stop_button_state" not in st.session_state:
st.session_state.stop_button_state = False
sd.play(data, sample_rate)
if stop_button or st.session_state.stop_button_state:
st.session_state.stop_button_state = True
sd.stop()
else:
sd.wait() # Wait until file is done playing
user_input = str(st.text_input("Name your file: "))
if user_input:
sweep_string = user_input + "_exponential_sweep_.wav"
inv_filter_string = user_input + "_inverse_filter_.wav"
ir_string = user_input + "_impulse_response_.wav"
st.write(sweep_string)
play_button = st.button("Play")
if "play_button_state" not in st.session_state:
st.session_state.play_button_state = False
if play_button or st.session_state.play_button_state:
st.session_state.play_button_state = True
sweep = generate_exponential_sweep(
sweep_duration_option, sample_rate_option, 20, 24000
)
inv_filter = generate_inverse_filter(
sweep_duration_option, sample_rate_option, sweep, 20, 24000
)
write_wav_file(file_name=sweep_string, rate=sample_rate_option, data=sweep)
write_wav_file(
file_name=inv_filter_string, rate=sample_rate_option, data=inv_filter
)
play_sweep(sweep_string)
The recorded sweep is deconvolved with the inversed sweep, finding the impulse response of the room.
Is it possible to record simultaneously or I’m better off abandoning the idea of doing a website for this and instead focus on buildin an offline app?
